Functions:
1.15-segment PEQ for Music , 7-segment stereo digital modulation control, adjustable noise gate control;
2.15-segments of dual channel PEQ for microphone, 4 levels of anti-howling;
3.Free drive USB connection, wireless WIFI debugging;
4.Control by iPhone,iPad and computer software;
5.3 sets of RCA, optical, coaxial input;
6.High-quality mufti-mode reverberation and echo technology;
7.Boot mode lock, volume lock function;
8.Manual automatic signal source input selection;
9.VOD computer number remote control interface;
10.Password setting, with engineering password lock;
11.Best Dsp Dante Controller For Home Audio And Linux Dante Controller Ipad.
Specification :
| Item | Specifications |
| Max Input Level | 18dBu |
| Max Output Level | 18dBu |
| Default Output Level | 0dBu |
| THD+N | <0.003%；1kHz@+4dBu
<0.0035%；1kHz@+10dBm
<0.0035%；20Hz～20kHz@+4dBu |
| Frequency Response | 20Hz-20kHz, +/-0.2dB |
| In To Out dynamic range | 110dB (Unrecorded right) |
| S/N | -110dB (Unrecorded right) |
| ADC Dynamic Range | CS5361 114dB |
| DAC Dynamic Range | CS4382A 114dB |
| DSP | 400Mhzfloating - point SHARC ADSP-21488 |
| Sampling Frequency | 48K |
| QE | 24Bit |
| Storage | 32 |
| Control Mode | 100M Ethernet |
| Language | English |
| Noise Gate | Yes |
| Feedback | Yes |
| Signal Generator | Yes |
| Pressure Limiter | Independent 12 channel |
| Delay | Output 1-4 218ms
Output 5-8 148ms |
PEQ
Low Shelf
High Shelf | Independent 16-band |
High Pass/Low Pass
Bessel
Butterworth
Link-Riley | Independent 12 channel
-6dB/oct
-12dB/oct
-18dB/oct
-24dB/oct
-36dB/oct
-48dB/oct |
| Product name | Best Dsp Dante Controller For Home Audio And Linux Dante Controller Ipad |
3.Typical System Application:
Dante Application: Dante network breaks through space limitations, and has a wide range of application scenarios.
It can connect all devices that support Dante protocol to the same local area network. By cascading 2 DSPs,
it supports the access of up to 32 analog microphones and 32 Dante microphones. Each processor will
conduct first-level auto mixing on its own microphones, and the second-level auto mixing is then made
on the mixed signal via the auto mixer of main processor so that more microphones can be connected
to build a larger auto mixing matrix. The two-level auto mixing working mode can satisfy general application scenarios.
Best Dsp Dante Controller For Home Audio And Linux Dante Controller Ipad.
